Animations

Swap out animation drivers per-platform or at runtime

import { LogoIcon } from '@tamagui/logo'
import { Play } from '@tamagui/lucide-icons'
import { Button, Square, useControllableState, useEvent } from 'tamagui'
export function AnimationsDemo(props) {
const [positionI, setPositionI] = useControllableState({
strategy: 'most-recent-wins',
prop: props.position,
defaultProp: 0,
})
const position = positions[positionI]
const onPress = useEvent(() => {
setPositionI((x) => {
return (x + 1) % positions.length
})
})
return (
<>
<Square animation={(props.animation || 'bouncy') as any} animateOnly={['transform']} onPress={onPress} size={104} borderColor="$borderColor" borderWidth={1} borderRadius="$9" backgroundColor="$color9" hoverStyle={{ scale: 1.5, }} pressStyle={{ scale: 0.9, }} {...position} >
{props.children || <LogoIcon downscale={0.75} />}
</Square>
<Button position="absolute" bottom={20} left={20} icon={Play} theme={props.tint} size="$5" circular onPress={onPress} />
</>
)
}
export const positions = [
{
x: 0,
y: 0,
scale: 1,
rotate: '0deg',
},
{
x: -50,
y: -50,
scale: 0.5,
rotate: '-45deg',
hoverStyle: {
scale: 0.6,
},
pressStyle: {
scale: 0.4,
},
},
{
x: 50,
y: 50,
scale: 1,
rotate: '180deg',
hoverStyle: {
scale: 1.1,
},
pressStyle: {
scale: 0.9,
},
},
]

Features

  • Animate any style prop with animation config per-prop.

  • Can animate across all states (media queries, hover, etc).

  • Three drivers you can swap out with type safety.

  • SSR safe mount animations.

  • Enter and exit animations with AnimatePresence.

Add animations to Tamagui with an animation driver. See the configuration docs for more on how to set it up, and how to set up different animation drivers per-platform.

Animation drivers are designed to be swappable, so you can use lightweight CSS animations or other web-focused animation libraries on the web, while using larger but more advanced libraries like reanimated on native - all without having to change a line outside of configuration.

Installation

CSS

The @tamagui/animations-css package works with the tamagui compiler and runtime to give you simple ways to share typed animations across all your components.

To install it add to your package.json:

yarn add @tamagui/animations-css

Then add it to your config:

import { createAnimations } from '@tamagui/animations-css'
import { createTamagui } from 'tamagui'
export default createTamagui({
animations: createAnimations({
fast: 'ease-in 150ms',
medium: 'ease-in 300ms',
slow: 'ease-in 450ms',
}),
// ...
})

At runtime, the plugin does very little except to set the transition property in CSS. At compile-time, the compiler does the same, ensuring you get all the benefits of prop removal and view flattening even when using animations.

React Native Animated

React Native's Animated library  is the animation library that comes built into React Native and React Native Web.

To install it add to your package.json:

yarn add @tamagui/animations-react-native

Then add it to your config:

import { createAnimations } from '@tamagui/animations-react-native'
import { createTamagui } from 'tamagui'
export default createTamagui({
animations: createAnimations({
fast: {
damping: 20,
mass: 1.2,
stiffness: 250,
},
medium: {
damping: 10,
mass: 0.9,
stiffness: 100,
},
slow: {
damping: 20,
stiffness: 60,
},
}),
// ...
})

Reanimated

Reanimated  is an animation library that targets React Native and React Native Web. It runs off-thread animations, and provides simple syntax and hooks.

To install it add to your package.json:

yarn add @tamagui/animations-moti react-native-reanimated

Tamagui leverages and appreciates the popular open source library Moti  for the Reanimated driver as it saved us many lines of complex code.

Add your animations to your configuration:

import { createAnimations } from '@tamagui/animations-moti'
import { createTamagui } from 'tamagui'
export default createTamagui({
animations: createAnimations({
fast: {
type: 'spring',
damping: 20,
mass: 1.2,
stiffness: 250,
},
medium: {
type: 'spring',
damping: 10,
mass: 0.9,
stiffness: 100,
},
slow: {
type: 'spring',
damping: 20,
stiffness: 60,
},
}),
// ...
})

At runtime, this plugin parses animatable style properties and hands them over to reanimated off-thread, using worklets. It doesn't do anything at compile time - reanimated must run via JS.

wwwwwwwwwwwwwwwwwww

Note the keys match between CSS and reanimated, so you can swap them out.

The Animated driver in React Native Web can be excluded from your bundle with either the Webpack or Next.js plugins with excludeReactNativeWebExports compiler option.

Usage

The animation can now accept slow as a value. By default, animations will apply to all animatable styles, a lot like setting all in a CSS transition. Let's test this by setting hoverStyle:

Here's an example animating hoverStyle:

import { LogoIcon } from '@tamagui/logo'
import { Square } from 'tamagui'
export function AnimationsHoverDemo() {
return (
<Square borderColor="$borderColor" animation="bouncy" elevation="$4" backgroundColor="$color9" size={104} borderRadius="$9" hoverStyle={{ scale: 1.2, }} pressStyle={{ scale: 0.9, }} >
<LogoIcon downscale={0.75} />
</Square>
)
}

A note on usage

As of beta 150, we're adding a rule for an edge case: any animated component that is removing or adding an animation at any time, keep the animation prop defined.

So, <Square animation={isActive ? 'bouncy' : null} /> rather than <Square {...isActive && { animation: 'bouncy' }} />. If you do absolutely need the latter, you must change the key at the same time.

Why? The animation hooks are heavy and would otherwise have to run on every component. Plus enter/exit animations further add renders. Tamagui is designed for performance in the happy path. If every component you render had to run all the animation logic, a lot of the performance of Tamagui would be nullified.

enterStyle

Setting enterStyle styles on any component tell it to start with those styles, and immediately transition into their regular styles:

import { LogoIcon } from '@tamagui/logo'
import { useRef, useState } from 'react'
import { Button, Square, YStack } from 'tamagui'
import { useIsIntersecting } from './useOnIntersecting'
export function AnimationsEnterDemo(props: any) {
const ref = useRef<HTMLElement>(null)
const hasIntersected = useIsIntersecting(ref, { once: true })
const [key, setKey] = useState(0)
if (!hasIntersected) {
return <YStack ref={ref} />
}
return (
<>
<Square key={key} enterStyle={{ scale: 1.5, y: -10, opacity: 0, }} animation="bouncy" elevation="$4" size={110} opacity={1} scale={1} y={0} backgroundColor="$pink10" borderRadius="$9" >
{props.children ?? <LogoIcon downscale={0.75} />}
</Square>
<Button size="$3" marginTop="$4" onPress={() => setKey(Math.random())}>
Re-mount
</Button>
</>
)
}

Granular animations

The animation prop accepts a string or a more complex object to customize animations per-property.

The basic object we'll call an AnimationConfig, looks like this:

import { YStack } from 'tamagui'
export default () => (
<YStack animation={{ // only x and y will apply animations x: 'bouncy', y: { type: 'bouncy', overshootClamping: true, }, }} />
)

Note that values can either map to AnimationKey as a string, or to { type: AnimationKey, ...configuration }

You can set a default value using a two-arity array with the default in the first position:

import { YStack } from 'tamagui'
export default () => (
<YStack animation={[ // all attributes get "bouncy" 'bouncy', // these are customized { y: 'slow', scale: { type: 'fast', repeat: 2, }, }, ]} />
)

animateOnly

The animateOnly prop will limit your animation config to certain keys. It accepts an array of strings that correspond to style property names.

AnimatePresence

exitStyle

AnimatePresence animates direct children before they unmount. It's inspired by and forked from Framer Motion , but works with any animation in Tamagui.

To use with @tamagui/core, install and import @tamagui/animate-presence. It's already bundled and exported from tamagui.

You can use it simply with enterStyle + exitStyle:

import { AnimatePresence, View } from 'tamagui'
export const MyComponent = ({ isVisible }) => (
<AnimatePresence>
{isVisible && (
<View key="my-square" animation="bouncy" backgroundColor="green" size={50} enterStyle={{ opacity: 0, y: 10, scale: 0.9, }} exitStyle={{ opacity: 0, y: -10, scale: 0.9, }} />
)}
</AnimatePresence>
)

Note you don't even need to set opacity on the base style. Tamagui knows to normalize styles like opacity and scale to 1 (and y to 0) if it's not defined on the base styles but is defined on enterStyle or exitStyle.

Wrap one or more tamagui components with AnimatePresence. This component will animate on enter and exit.

Animated child components must each have a unique key prop so AnimatePresence can track their presence in the tree.

The custom prop

import { AnimatePresence } from '@tamagui/animate-presence'
import { ArrowLeft, ArrowRight } from '@tamagui/lucide-icons'
import { useState } from 'react'
import { Button, Image, XStack, YStack, styled } from 'tamagui'
// @ts-ignore
import photo1 from '../../public/photo1.jpg'
// @ts-ignore
import photo2 from '../../public/photo2.jpg'
// @ts-ignore
import photo3 from '../../public/photo3.jpg'
export const images = [photo1, photo2, photo3].map((x) => x.src || x)
const GalleryItem = styled(YStack, {
zIndex: 1,
x: 0,
opacity: 1,
fullscreen: true,
variants: {
// 1 = right, 0 = nowhere, -1 = left
going: {
':number': (going) => ({
enterStyle: {
x: going > 0 ? 1000 : -1000,
opacity: 0,
},
exitStyle: {
zIndex: 0,
x: going < 0 ? 1000 : -1000,
opacity: 0,
},
}),
},
} as const,
})
const wrap = (min: number, max: number, v: number) => {
const rangeSize = max - min
return ((((v - min) % rangeSize) + rangeSize) % rangeSize) + min
}
export function AnimationsPresenceDemo() {
const [[page, going], setPage] = useState([0, 0])
const imageIndex = wrap(0, images.length, page)
const paginate = (going: number) => {
setPage([page + going, going])
}
return (
<XStack overflow="hidden" backgroundColor="#000" position="relative" height={300} width="100%" alignItems="center" >
<AnimatePresence initial={false} custom={{ going }}>
<GalleryItem key={page} animation="slowest" going={going}>
<Image source={{ uri: images[imageIndex], width: 820, height: 300 }} />
</GalleryItem>
</AnimatePresence>
<Button accessibilityLabel="Carousel left" icon={ArrowLeft} size="$5" position="absolute" left="$4" circular elevate onPress={() => paginate(-1)} zi={100} />
<Button accessibilityLabel="Carousel right" icon={ArrowRight} size="$5" position="absolute" right="$4" circular elevate onPress={() => paginate(1)} zi={100} />
</XStack>
)
}

AnimatePresence also takes a custom property that allows you to update a variant of the animated child before it runs it's exit animation. This is useful for animating a child out of the screen before it unmounts in a different direction, like the example above:

import { AnimatePresence } from '@tamagui/animate-presence'
import { ArrowLeft, ArrowRight } from '@tamagui/lucide-icons'
import { useState } from 'react'
import { Button, Image, XStack, YStack, styled } from 'tamagui'
const GalleryItem = styled(YStack, {
zIndex: 1,
x: 0,
opacity: 1,
fullscreen: true,
variants: {
// 1 = right, 0 = nowhere, -1 = left
going: {
':number': (going) => ({
enterStyle: {
x: going > 0 ? 1000 : -1000,
opacity: 0,
},
exitStyle: {
zIndex: 0,
x: going < 0 ? 1000 : -1000,
opacity: 0,
},
}),
},
} as const,
})
const photos = [
'https://picsum.photos/500/300',
'https://picsum.photos/501/300',
'https://picsum.photos/502/300',
]
const wrap = (min: number, max: number, v: number) => {
const rangeSize = max - min
return ((((v - min) % rangeSize) + rangeSize) % rangeSize) + min
}
export function Demo() {
const [[page, going], setPage] = useState([0, 0])
const imageIndex = wrap(0, photos.length, page)
const paginate = (going: number) => {
setPage([page + going, going])
}
return (
<XStack overflow="hidden" backgroundColor="#000" position="relative" height={300} width="100%" alignItems="center" >
<AnimatePresence initial={false} custom={{ going }}>
<GalleryItem key={page} animation="slowest" going={going}>
<Image source={{ uri: photos[imageIndex], width: 500, height: 300 }} />
</GalleryItem>
</AnimatePresence>
<Button accessibilityLabel="Carousel left" icon={ArrowLeft} size="$5" position="absolute" left="$4" circular elevate onPress={() => paginate(-1)} zi={100} />
<Button accessibilityLabel="Carousel right" icon={ArrowRight} size="$5" position="absolute" right="$4" circular elevate onPress={() => paginate(1)} zi={100} />
</XStack>
)
}

What to know when animating

Conditional animations and HMR

The animation hooks are heavy, which initially meant we either had to choose great performance or animations. We've settled on a trade-off. We track if the animation prop is set, and if so, we enable the hook. If it is ever set, even just once, then the hooks will continue to run for the remainder of the component lifecycle. This means if you ever plan to animate a component you should keep animation always set on the component props. You can disable it like so:

<View animation={condition ? 'animation-name' : null} />

Note that because of this constraint, you also will see an error if you add the animation prop to a component in dev mode during an HMR. Often just saving once more will remove the screen, or reloading at worst.

Server side rendered enter animations on web

To get easy, safe and ideal server side rendering, Tamagui avoids rendering using the spring animation drivers on the server. Instead, it uses the CSS driver so that it can generate both enter-style and non-enter-style CSS, with the enter-style CSS under the new selector .t_unmounted.

On the first load in a browser, to avoid hydration mis-matches ), Tamagui renders once more using the CSS driver. Finally, it renders again (only for components with both animation and enterStyle set), swapping in the spring driver and removing the t_unmounted selector so that the enter animations hand off without any visible difference. But you have to add one script tag to the head element, from the server:

<head>
<script dangerouslySetInnerHTML={{ // avoid flash of entered elements before enter animations run: // https://tamagui.dev/docs/core/animations#server-side-rendered-enter-animations-on-web __html: `document.documentElement.classList.add('t_unmounted')`, }} />
</head>

This adds the className t_unmounted to your body tag only if JavaScript is enabled. If a user doesn't have JavaScript on, they see the normal page, without any hidden elements. If they do have JavaScript on, because this script runs in the head before the browser has any body to show, browsers will add the t_unmounted className on first render and your content will be in the "entering" state, or else it would flicker the "entered" content.
